- 7-inch color touchscreen
- 300DPI high-resolution printing
- RS232 interface for variable data printing
- Print height: 2-25.4mm
- Support multinational language
- Support there color alarm system
The fine-tuning device makes
the inkjet printing height is more accurate EXP
Say goodbye to online printing content distortion
Support U disk import database printing
The USB flash drive imports the edited TXT text to the machine to complete the database printing
7-inch large high-definition capacitor screen
Industrial grade protective metal mainframe, it is made of aluminum, with lightweight, height strength and corrosion resistance
Parameter
| Nozzle type: | TIJ 2.5 thermal foaming nozzle |
| Printing accuracy: | 300DPI |
| Printing height: | 2-25.4mm |
| Print distance: | 2-5mm |
| Printing speed: | 40m/min |
| Printing content: | Text, time picture, dynamic barcode/QR code |
| Printing material: | Plate, carton, pipe, cable, metal, plastic, etc |
| Print library: | Synchronous machine library |
| Ink type: | Quick dry ink/42ml, water-based/42ml, oily/42ml |
| Ink color: | Black, white, red, yellow, blue, green, invisible |
| Ink cartridge chip: | RFID non-contact chip, automatic identification of the best ink parameters and record ink margin |
| Bar Code Type: | Code 128, Code39, Int25, UPCA, ENA13, QR Code, Data Matrix |
| Operating system: | Linux 3.4 |
| External interface: | Power and optoelectronic interface, HDMI cable interface, USB interface |
| Support language: | Chinese, English, Russian, French, Spanish, Japanese, Korean, Arabic, etc |
| Power adapter: | 100-240V AC input, 16V/5A DC output |
Packing list
